Product Details
KEY FEATURES & BENEFITS
Made in USA at our facility in Mooresville, NC
Forged aerospace aluminum body for maximum stiffness at high temperature
Designed for superior stiffness and minimal lateral deflection; improves release characteristics
Standard 180 x 42mm radial mount easily replaces existing products
Stainless steel pad abutments prevent pads from binding in calipers
Stainless steel pistons for extended piston life
7 lbs. anti-knockback springs installed
SPECIFICATION
Rotor Size 12.16 – 13” x 1.26” (309 – 330 x 32mm)
Piston size 1.10” / 1.26” / 1.50” (28 / 32 / 38mm)
Pad thickness 0.98” (25 mm)
High airflow rotors 12.19×1.26” (309.6mm x 32 mm), 48 vane, 13.8 lbs. (6.25 kg)
Rear caliper weight 7.87 lbs. (3.57 kg)
Pad shapes Project Mu TA001.25.**, .20 (H20), .21 (H21) & .04 (RW04) Pagid
Fluid Inlet / Bleed screws 3/8” – 24 UNF
